SP8. Offers various solutions for connecting the stud to the top and bottom plates. 20-gauge galvanized steel. May also be available with ZMAX coating. No. SP1: Size: 3-1/2" W x 5-1/16" L, Material: Galvanized Steel, Gauge: 20 ga, Install WIth: 6-10d fastner(stud)&4-10d fastner(plate) No. SP1Z: Size: 3-1/2" W x 5-1/16" L, Material: Galvanized Steel, Gauge: 20 ga, Finish: Z-Max, Install WIth: 6-10d fasteners on stud No. SP2: Size: 3-1/2" W x 6-5/8" L, Material: Galvanized Steel, Gauge: 20 ga,...

HU14. Most models have triangle and round holes. To achieve maximum loads, fill both round and triangle holes with common nails. These heavy-duty connectors are designed for schools and other structures requiring additional strength, longevity, and safety factors. 14-gauge galvanized steel. No. HU9: Size: 1-13/16" W x 9-5/16" H x 2-1/2" Base, Joist Size: 2" x 10", Type: HU Face Mount, Material: Galvanized Steel, Finish: Galvanized, Gauge: 14 ga, Install With: 18-16d face, 6-10d x 1-1/2" joist,...

H4. Provides resistance to uplift and lateral forces. Designed to help counter the effect of high wind and seismic events on a structure. Used also for general tie purposes, strongback attachments, and as an all-purpose tie where 1 member crosses another. Install in pairs to connect 2x rafter to top plate. Some sizes available with ZMAX coating. No. H1: Material: Galvanized Steel, Gauge: 18 ga, Finish: Galvanized, Carton Qty: 100/Carton, Fastners to Rafters: 6-8dx1-1/2, Fasteners to Plates:...

P22AC2 Simpson Strong-Tie .22 Caliber Power Load SKU # For use in low-velocity tools. Use in tools from Simpson Strong Tie, Ramset, Cobra, Viper, Hilti, and Remington. High quality and dependability. All loads are color coded and load level numbered. As the number increases, the power level increases. Always start with the lightest strip load. If the fastener does not set completely, use the next higher load and repeat the process. No. P22AC2: Caliber: 0.22 Caliber/Single, Power Level: Level...

BIT2P-RC3 Quik Drive Screwdriver Bit Pack SKU # 3 screwdriving bits for use with Quik Drive fastening system. No. BIT2P-RC3: Size: Phillips #2, Pkg Qty: 3, Package Type: Box No. BIT2SU-RC3: Size: Undersized Square Recess #2, Pkg Qty: 3, Package Type: Box No. BIT3S-RC3: Size: Square Recess #3, Pkg Qty: 3, Package Type: Box No. BIT3SU-RC3: Size: Undersized Square Recess #3, Pkg Qty: 3, Package Type: Box

BIT2SU-RC3 Quik Drive Screwdriver Bit Pack SKU # 3 screwdriving bits for use with Quik Drive fastening system. No. BIT2P-RC3: Size: Phillips #2, Pkg Qty: 3, Package Type: Box No. BIT2SU-RC3: Size: Undersized Square Recess #2, Pkg Qty: 3, Package Type: Box No. BIT3S-RC3: Size: Square Recess #3, Pkg Qty: 3, Package Type: Box No. BIT3SU-RC3: Size: Undersized Square Recess #3, Pkg Qty: 3, Package Type: Box

FB26 Simpson Strong-Tie FB26 Fence Bracket SKU # 100506Simpson Strong-Tie fence brackets make the connection between fence rails and posts simple and strong. Eliminates the need for toe-nailing or screwing. Clean, versatile connections make planning and building fences, deck/porch railing, and louvers easier and faster. Designed to provide a connection between 2x6 fence rails and 4x4 fence posts. Ideal for miscellaneous fastening of 2x6 ends. Install with 8d common, 8d x 1-1/2" nails, or #9 x...

P22AC3 Simpson Strong-Tie .22 Caliber Power Load SKU # For use in low-velocity tools. Use in tools from Simpson Strong Tie, Ramset, Cobra, Viper, Hilti, and Remington. High quality and dependability. All loads are color coded and load level numbered. As the number increases, the power level increases. Always start with the lightest strip load. If the fastener does not set completely, use the next higher load and repeat the process. No. P22AC2: Caliber: 0.22 Caliber/Single, Power Level: Level...

P22AC4 Simpson Strong-Tie .22 Caliber Power Load SKU # For use in low-velocity tools. Use in tools from Simpson Strong Tie, Ramset, Cobra, Viper, Hilti, and Remington. High quality and dependability. All loads are color coded and load level numbered. As the number increases, the power level increases. Always start with the lightest strip load. If the fastener does not set completely, use the next higher load and repeat the process. No. P22AC2: Caliber: 0.22 Caliber/Single, Power Level: Level...

MSTC48B3 Pre-Bent Strap TiePre-bent straps designed to transfer tension load from an upper story shearwall to a beam on the story below. 14-gauge, galvanized steel. No. MSTC48B3: Size: 3" W x 44-7/8" L x 2-7/8" pre-bent, Material: Steel, Gauge: 14 ga, Finish: Galvanized, Pkg Qty: 1 No. MSTC66B3: Size: 3" W x 66-7/8" L x 2-7/8" pre-bent, Material: Steel, Gauge: 14 ga, Finish: Galvanized, Pkg Qty: 1

CPS5 Standoff BaseThe CPS is a composite plastic standoff designed for increased concrete surface area. No. CPS6: 5-5/16" L. x 5-5/16" W. x 1" H., use 4-10d fasteners in post and 5/8" anchor bolt. No. CPS4: 3-1/4" L. x 3-1/4" W. x 1" H., use 4-10d fasteners in post and 5/8" anchor bolt. No. CPS5: 4-1/8" L. x 4-1/8" W. x 1" H., use 4-10d fasteners in post and 5/8" anchor bolt. No. CPS4: Size: 3-1/4" x 3-1/4" x 1", Post Size: 4" x 4", Material: Plastic, Gauge: N/A, Type: Standoff, Finish: Black,...

CB44 Simpson Strong-Tie Column BaseSimpson Strong-Tie column bases, install all models with bottom of base plate flush with the concrete. Post bases do not provide adequate resistance to prevent members from rotating about the base and therefore are not recommended for non top-supported installations (such as fences or unbraced carports). Strap is 7-gauge x 2" width. Base is 7-gauge. No. CB44: Size: 3-9/16" W1 x 3-9/16" W2 x 8" D, Post Size: 4"x4", Material: Galvanized Steel, Gauge: 7 ga,...

ABW44Z Simpson Strong-Tie ABW Post BaseAn adjustable retrofit post base with a 1" standoff and increased capacity to resist uplift loads. Features a slot in the ABW that allows flexible positioning around the anchor bolt making precise post placement easier. The 1" standoff helps prevent rot at the end of the post and meets code requirements for structural post that are installed in basements or exposed to weather or water splash. Installs with nails or structural-connector screws. Finish ZMAX...

ABW46RZ Simpson Strong-Tie ABW Post BaseAn adjustable retrofit post base with a 1" standoff and increased capacity to resist uplift loads. Features a slot in the ABW that allows flexible positioning around the anchor bolt making precise post placement easier. The 1" standoff helps prevent rot at the end of the post and meets code requirements for structural post that are installed in basements or exposed to weather or water splash. Installs with nails or structural-connector screws. Finish...

U214 Simpson Strong-Tie U Face Mount Joist HangerThe standard U hanger provides flexibility of joist to header installation. Versatile fastener selection with tested allowable loads. 16-gauge galvanized steel. No. U26: Size: 1-9/16" W x 4-3/4" H x 2" Base, Joist Size: 2" x 6", Type: Face Mount, Material: Steel, Finish: Galvanized, Gauge: 16 ga, Install With: 6-10d or 6-16d in header 4-10dx1-1/2", Pkg Qty: 1 No. U26-2: Size: 3-1/8" W x 5" H x 2" Base, Joist Size: 2" x 6", Type: Face Mount,...

PF24B 18-Gauge Post Frame HangerThe PF post frame hanger has patented double shear nailing to speed installation. Diamond holes allow easy alignment and attachment. Carried member nails must be driven at an angle through the joist into the header to achieve catalog table loads. Cannot be modified. No. PF24Z: Size: 1-9/16"W x 3-3/8" H x 1 - 1/2" base, Material: Galvanized Steel, Finish: Z-Max, Gauge: 18 ga, Install With: 2-10d fasteners, Pkg Qty: 1 No. PF26Z: Size: 1-9/16" W x 5-3/8" H x 1-1/2"...

CPT44Z Simpson Strong-Tie Concealed Post BaseBoth Model No. CPTZ44 and CPTZ66 post bases incorporate a knife plate with a standoff base. It achieves a clean, concealed look while providing a 1" standoff height above the concrete. The concealed post base is installed with 1/2" dia (diameter) galvanized pins (supplied). No. CPT44Z: Size: Rough 4" x 4", Post Size: 3-1/2" x 3-1/2", Material: Steel, Gauge: 10 ga, Type: Standoff, Finish: ZMAX, Install With: Anchor 2, 5/8" dia; Post 3,1/2" x 2-3/4",...

CPT66Z Simpson Strong-Tie Concealed Post BaseBoth Model No. CPTZ44 and CPTZ66 post bases incorporate a knife plate with a standoff base. It achieves a clean, concealed look while providing a 1" standoff height above the concrete. The concealed post base is installed with 1/2" dia (diameter) galvanized pins (supplied). No. CPT44Z: Size: Rough 4" x 4", Post Size: 3-1/2" x 3-1/2", Material: Steel, Gauge: 10 ga, Type: Standoff, Finish: ZMAX, Install With: Anchor 2, 5/8" dia; Post 3,1/2" x 2-3/4",...

THA422 THA422 Simpson Strong-Tie Adjustable Truss HangerThe THA series extra long straps allow full code nailing and can be field-formed to give top flange hanger convenience. Designed for 4x2 floor trusses and 4x beams. Top flange installations, straighten the double shear nailing tabs and install the nails straight into the joist. For face mount installation, install all face nails according to the table. On models where there are more nails holes than required, the lowest 4 face holes must...

LBP5/8Z Simpson Strong-Tie Bearing PlateBearing plates give greater bearing surface than standard cut washers and help distribute the load at these critical connections. No. BP1/2: Size: 2" x 2" x 3/16", Material: Steel, Finish: Uncoated, Install with: 1/2" diameter bolt, Pkg Qty: 1 No. LBP1/2: Size: 2" x 2" x 9/64", Material: Steel, Finish: Galvanized, Install with: 1/2" diameter bolt, Pkg Qty: 1 No. BP1/2HDG: Size: 2" x 2" x 3/16", Material: Steel, Finish: Hot Dipped Galvanized, Install...

HUS412 Simpson Strong-Tie HUS Double Shear Joist HangerFeatures double shear nailing that distributes the load through 2 points on each joist nail for greater strength. This allows for fewer nails, faster installation, and the use of all common nails for the same connection. Do not bend or removed tabs. Galvanized for extra corrosion resistance. No. HUS26: Size: 3-1/8" W x 5-3/16" H x 2" Base, Joist Size: 2" x 6", Type: Double Shear, Material: Steel, Finish: Galvanized, Gauge: 16 ga, Install...

HHUS48 Simpson Strong-Tie HHUS Slant Nail Joist HangerAll hangers in this series have double shear nailing - an innovation that distributes the load through 2 points on each joist nail for greater strength. This allows for fewer nails, faster installation, and the use of all common nails for the same connection. Nails must be driven at an angle through the joist or truss into the header to achieve the table loads. Not designed for welded or nailer applications. Galvanized. 14-gauge. No....

HGUS412 Simpson Strong-Tie HGUS Double Shear HangerUsed for high load applications. Double shear nailing distributes the load through 2 points on each joist nail for greater strength. Allows the use of fewer nails, faster installation, and the use of common nails for all connections. No. HGUS28-2: Size: 3-5/16" W x 7-3/16" H x 4" B, Joist Size: 2 In. x 8 In., Type: Double Shear, Material: Steel, Finish: Galvanized, Gauge: 12 ga, Install With: 36-16d Header / 12-16d Joist, Pkg Qty: 1 No....

N10D5HDG-R Simpson Strong-Tie Joist NailSimpson Strong-Tie nails and fasteners have been developed as the optimum fasteners for connector products. Special lengths afford economy of purchase and installation, and depth compatibility with framing members. They are packed in resealable containers for easy handling. Hot-dip galvanized. No. N8DHDG-R: Length: 1-1/2", Diameter: 0.131", Package Size: 1 lb, Head Diameter: 0.313", Finish: Hot Dipped Galvanized, Shank Type: Smooth, Head Type: Flat,...
