Square D Co.

FSG2J21CP Square D Pumptrol Pressure SwitchDesigned for the control of electrically driven water pumps. Compatible with jet pumps, submersible pumps, and reciprocating pumps. Diaphragm actuated, 2 poles, 1/4" - 18 NPSF (internal thread). No. FSG2J20CP: Pressure Rating: 20 - 40 psi, Type: Diaphragm Actuated, Contact Type: 2 Pole, Thread: 1/4" - 18 NPSF (Internal), Pkg Qty: 1, Package Type: Box No. FSG2J21CP: Pressure Rating: 30 - 50 psi, Type: Diaphragm Actuated, Contact Type: 2 Pole, Thread:...

FSG2J20M4CP Square D 1/4" Pumptrol Pressure SwitchFeatures low water cut-off switch to shut off pump at 12 P.S.I. to prevent overheating damage to submersible well pumps. Recommended for submersible pumps. Compatible with jet pumps, submersible pumps, and reciprocating pumps. The standard action contacts open on rising pressure. Diaphragm actuated - 1/4" 18 NSF internal threads. No. FSG2J20M4CP: Pressure Rating: 20 - 40 psi, Type: Electrically Driven Water Pumps, Contact Type: Diaphragm...

FSG2J20PCP Square D Pumptrol Pressure Switch With Pulsation PlugDesigned for the control of electrically driven water pumps. Compatible with jet pumps, submersible pumps, and reciprocating pumps. Includes pulsation plug designed to protect pressure switch components from a plumbing system that may experience water hammer. Diaphragm actuated, 2 poles, 1/4 In. - 18 NPSF (internal thread). No. FSG2J20PCP: Pressure Rating: 20 - 40 psi, Type: Diaphragm Actuated, Contact Type: 2 Pole, Thread: 1/4" -...

FSG2J20CP Square D Pumptrol Pressure SwitchDesigned for the control of electrically driven water pumps. Compatible with jet pumps, submersible pumps, and reciprocating pumps. Diaphragm actuated, 2 poles, 1/4" - 18 NPSF (internal thread). No. FSG2J20CP: Pressure Rating: 20 - 40 psi, Type: Diaphragm Actuated, Contact Type: 2 Pole, Thread: 1/4" - 18 NPSF (Internal), Pkg Qty: 1, Package Type: Box No. FSG2J21CP: Pressure Rating: 30 - 50 psi, Type: Diaphragm Actuated, Contact Type: 2 Pole, Thread:...

FSG2J21M4CP Square D 1/4" Pumptrol Pressure SwitchFeatures low water cut-off switch to shut off pump at 12 P.S.I. to prevent overheating damage to submersible well pumps. Recommended for submersible pumps. Compatible with jet pumps, submersible pumps, and reciprocating pumps. The standard action contacts open on rising pressure. Diaphragm actuated - 1/4" 18 NSF internal threads. No. FSG2J20M4CP: Pressure Rating: 20 - 40 psi, Type: Electrically Driven Water Pumps, Contact Type: Diaphragm...

FSG2J24CP Square D Pumptrol Pressure SwitchDesigned for the control of electrically driven water pumps. Compatible with jet pumps, submersible pumps, and reciprocating pumps. Diaphragm actuated, 2 poles, 1/4" - 18 NPSF (internal thread). No. FSG2J20CP: Pressure Rating: 20 - 40 psi, Type: Diaphragm Actuated, Contact Type: 2 Pole, Thread: 1/4" - 18 NPSF (Internal), Pkg Qty: 1, Package Type: Box No. FSG2J21CP: Pressure Rating: 30 - 50 psi, Type: Diaphragm Actuated, Contact Type: 2 Pole, Thread:...

9036DG2R Square D Float Pump SwitchPumps up to 2 HP at 120 VAC. Used directly or through a magnetic starter. Force to trip 9 oz up, 8 oz down. -22 deg (degrees) F (Fahrenheit) to 250 deg F. Boxed. UL (Underwriter's Laboratories) listed. No. 9036DG2R: Force to Trip: 9 oz Up, 8 oz Down, Temperature Rating: -22 F To 250 F, Horsepower: 2 HP at 120 VAC, Pkg Qty: 1, Package Type: Box

QO124M100PC Square D QO 100A Indoor Main Breaker Plug-on Neutral Load CenterType QO load center with cover and main breaker installed. Plug-on Neutral ready and built with a shielded, copper bus bar that is plated for reliability. 100 amp main breaker included. Ideal for residential, commercial, and industrial power distribution. Engineered for fast installation and wire savings. UL (Underwriter's Laboratories) listed for residential, commercial, and industrial power distribution. No....

QO142M200PC Square D QO 200A Indoor Main Breaker Plug-on Neutral Load CenterType QO load center with cover and main breaker installed. Plug-on Neutral ready and built with a shielded, copper bus bar that is plated for reliability. 200 amp main breaker included. Ideal for residential, commercial, and industrial power distribution. Engineered for fast installation and wire savings. UL (Underwriter's Laboratories) listed for residential, commercial, and industrial power distribution. No....

HOME250SPA Square D Homeline Spa Panel Main Lug Load CenterSquare D Homeline 2-space, 4-circuit spa pack load center. Protects single pole and double pole loads against ground and overcurrent faults. Provides protection for outdoor circuits such as hot tubs, fountains, swimming pools, or spas. Engineered for fast installation and wire savings. Includes (1) 50 amp Homeline outdoor metallic load center with an installed HOM250GFI. No. HOME250SPA: Series: Homeline, Amperage: 50A, Number Of...

HOM2040M100PCVP Square D Homeline Main Breaker Plug-on Neutral Load Center Remodeler PackSquare D Homeline 40-circuit main breaker load center value pack. Plug-on Neutral ready, features a plated aluminum bus,that is tested and listed only for Homeline circuit breakers. 100 amp main breaker included. Also includes (2) 20 amp single-pole (HOM120) circuit breakers, (1) 30 amp double-pole (HOM230) circuit breaker, and cover. UL (Underwriter's Laboratories) listed for residential and commercial...

HOM2040M100PC Square D Homeline 100A Main Breaker Plug-on Neutral Load CenterSquare D Homeline indoor convertible main breaker load center. For residential and commercial power distribution. Plug-on Neutral ready and built with a plated, aluminum bus bar that is tested and listed only for Homeline circuit breakers. 100 amp main breaker included. Engineered for fast installation and wire savings. UL (Underwriter's Laboratories) listed for residential and commercial power distribution. No....

HOM816L125PC Square D Homeline Indoor Main Lug Plug-on Neutral Load CenterSquare D Homeline indoor, convertible, main lugs load center. Plug-on Neutral ready and built with a plated, aluminum bus bar that is tested and listed only for Homeline circuit breakers. Ground bar is factory installed. Designed for the value-minded contractors, remodelers, builders, and homeowners. Engineered for fast installation and wire savings. No. HOM1224L125PGC: Series: Homeline, Amperage: 125A, Number Of Spaces:...

HOM612L100RBCP Square D Homeline Outdoor Main Lug Load CenterHomeline, main lugs only. Can be used when spaces for more circuits are needed, as a secondary or add on load center connected to the main disconnect load center. Single-phase, 3-wire. Cover included, ground bar kits must be ordered separately. Accepts only Homeline circuit breakers. Ideal for residential and commercial power distribution. Built with plated, aluminum bus bar that is tested and listed only for Homeline circuit...

HOM612L100SCP Square D Homeline Indoor Main Lug Load CenterHomeline, main lugs only. Can be used when spaces for more circuits are needed, as a secondary or add on load center connected to the main disconnect load center. Single-phase, 3-wire. Cover included, ground bar kits must be ordered separately. Accepts only Homeline circuit breakers. Ideal for residential and commercial power distribution. Built with plated, aluminum bus bar that is tested and listed only for Homeline circuit breakers....

HOM3060M200PC Square D Homeline 200A Main Breaker Plug-on Neutral Load CenterSquare D Homeline indoor convertible main breaker load center. For residential and commercial power distribution. Plug-on Neutral ready and built with a plated, aluminum bus bar that is tested and listed only for Homeline circuit breakers. 200 amp main breaker included. Engineered for fast installation and wire savings. UL (Underwriter's Laboratories) listed for residential and commercial power distribution. No....

QO2020CP Square D QO Single-Pole Tandem Circuit BreakerQO single-pole tandem circuit breaker. Ideal for overload and short-circuit protection of electrical systems. Offers 2 circuits in the space of 1. Compatible with QO load centers, CSED devices, and NQOD panel boards. Equipped with the exclusive Visi-Trip indicator. Only to be used in load centers built prior to 1967. When breaker is tripped, the handle snaps to a midpoint position and a highly visible, red indicator easily identifies the...

HOM4080M200PCVP Square D Homeline 200A Value Pack Plug-On Neutral Load CenterSquare D Homeline indoor main breaker load center value pack. For residential and commercial power distribution. Plug-on Neutral ready and built with a plated, aluminum bus bar that is tested and listed only for Homeline circuit breakers. 200 amp main breaker. Also includes (3) 20 amp single-pole (HOM120) circuit breakers, (2) 30 amp double-pole (HOM230) circuit breakers, and cover. Engineered for fast installation...

HOM24L70RBCP Square D Homeline Outdoor Main Lug Load CenterHomeline, main lugs only. Can be used when spaces for more circuits are needed, as a secondary or add on load center connected to the main disconnect load center. Single-phase, 3-wire. Cover included, ground bar kits must be ordered separately. Accepts only Homeline circuit breakers. Ideal for residential and commercial power distribution. Built with plated, aluminum bus bar that is tested and listed only for Homeline circuit breakers....

HOMT1515CP Square D Homeline Single-Pole Tandem Circuit BreakerHomeline tandem circuit breaker. 2 single-poles requiring 1 space. Used for overload and short-circuit protection of electrical systems. Compatible with Homeline load centers and CSED devices. Rated for 120 volt/240 volt and 10,000 AIR. Designed exclusively for the residential market. ANSI (American National Standards Institute) certified and UL (Underwriter's Laboratories) listed. No. HOMT1515CP: Amperage: 15A/15A, Number of...

HOM120GFICP Square D Homeline Single-Pole GFCI BreakerHomeline GFCI (ground fault circuit interrupter) breaker. Helps protect against dangerous electrical shock. Single-pole, 1 space required. Compatible with Homeline load centers and CSED devices. ANSI (American National Standards Institute) certified and UL (Underwriter's Laboratories) listed. Rated for 120 volts and 10,000 AIR. No. HOM120GFICP: Amperage: 20A, Number of Poles: 1-Pole, Interruption Type: GFCI, Voltage: 120V, Frame Size:...

HOM270CP Square D Homeline Circuit BreakerHomeline circuit breaker. Used for overload and short-circuit protection of electrical systems. Compatible with Homeline load centers and CSED devices. Rated for 120 volt/240 volt and 10,000 AIR. Designed exclusively for the residential market. ANSI (American National Standards Institute) certified and UL (Underwriter's Laboratories) listed.

HOM260C Square D Homeline Circuit BreakerHomeline circuit breaker. Used for overload and short-circuit protection of electrical systems. Compatible with Homeline load centers and CSED devices. Rated for 120 volt/240 volt and 10,000 AIR. Designed exclusively for the residential market. ANSI (American National Standards Institute) certified and UL (Underwriter's Laboratories) listed.

HOM250C Square D Homeline Circuit BreakerHomeline circuit breaker. Used for overload and short-circuit protection of electrical systems. Compatible with Homeline load centers and CSED devices. Rated for 120 volt/240 volt and 10,000 AIR. Designed exclusively for the residential market. ANSI (American National Standards Institute) certified and UL (Underwriter's Laboratories) listed.
